Company profile:
Shanghai Nikkiso Canned Pump Co., Ltd. was established in February 1994. At the beginning of its establishment, the company was a Sino-Japanese joint venture. In December 2002, in order to seek new development of the enterprise, the company moved from Jinshan District to Fengxian District. In October 2006, Japan's Nikkiso Group acquired the Chinese shares in an all-round way. The company changed from a joint venture to a wholly-owned enterprise. Specializing in the production and sales of canned motor pumps.
Nikkiso Co., Ltd. is a leading advocate of canned motor pumps and one of the largest canned motor pump manufacturers in the world. The earliest developed canned motor pump was originally to meet the needs of the nuclear power industry, requiring the pump to be completely leak-free and highly reliable. For more than half a century, Nikkiso has been continuously engaged in the research and development of canned motor pumps and implemented strict scientific management, so that its products are well-known all over the world for their excellent performance, best quality assurance and reliable operation. Nikkiso Co., Ltd. was the first to obtain ISO9001 certification in the Japanese pump industry.
Product Features:
1. Automatic thrust balance
The automatic thrust balance provided by the hydrodynamic action of the fixed throttle ring and the variable throttle ring keeps the shaft in the middle of the thrust bearing, thus eliminating the wear of the thrust bearing during normal operation. The abnormal wear between the thrust washer and the thrust surface of the graphite bearing only occurs in the accidental situation of poor starting and inlet suction.
2. Bearing monitor
Mechanical bearing monitor:
The mechanical bearing monitor is composed of a detection probe and a pressure indicator. The probe of the detection part is installed in the end nut of the shaft end and fixed on the rear bearing seat at the same time. The detection probe is sealed with pressurized argon gas. When the bearing wears radially or axially, the shaft will vibrate. Cause the rotor to exceed the normal range, cause the detection part and the end nut to contact and wear, causing the pressure in the monitor to drop (or rise) and the pressure indicator indicates abnormality. In addition, since the detection part of the mechanical bearing monitor uses the same material as the pump, it can also monitor the corrosion of the material in the pump. Because fluorine oil is injected between the meter body and the probe, the entire structure guarantees the pressure resistance requirements. There are electrical bearing monitors and electronic bearing monitors
3. Dry running protection device
The air transport protection device is to avoid dry operation and cavitation operation. When the system is evacuated, cut off or cavitation occurs, this device will send out a signal to drive and protect the pump device.
4. Steering detector
It is usually difficult to detect the direction of rotation of the canned motor pump. The steering detector of Nikkiso is a measuring instrument that can detect the magnetic field of the canned motor pump from the outside, and use the LED indicator to indicate the direction of the motor's forward and reverse rotation.
Typical application:
Nikki-installed canned motor pumps are extremely suitable for petrochemical, chemical, pharmaceutical, food, air-conditioning, refrigeration and environmental applications that require no leakage, corrosion resistance, inflammable and explosive applications. The detailed materials and media are as follows:
|
Acids
|
Sulfuric acid, nitric acid, mixed acid, phosphoric acid, hydrocyanic acid, chromic acid, acetic acid, oxalic acid, lactic acid, methacrylic acid, chlorosulfonic acid, fatty acid, boric acid
|
|
Salt
|
Calcium chloride, sodium chloride, sodium carbonate, ammonium sulfate, sodium sulfide, sodium cyanide, potassium dichromate, lithium chloride, ammonium sulfite, sodium hypochlorite, sodium chlorate, lithium bromide
|
|
Alkali
|
Caustic soda, caustic potassium, ammonia
|
|
Ester
|
Methyl acetate, ethyl acetate, amyl acetate, methyl methacrylate
|
|
Aromatics
|
Benzene, toluene, xylene, phenol, naphthalene, dichlorobenzene, cresol, methyl naphthalene, alkylbenzene
|
|
Hydrocarbon
|
Butane, hexane, propane, ethylene, propylene, cyclohexane
|
|
Alcohols
|
Methanol, ethanol, butanol, isopropanol, octanol, glycerin, ethylene glycol, propylene glycol
|
|
Oxygen compounds and ethers
|
Formaldehyde, acetaldehyde, benzaldehyde, methyl ether, ethyl ether, acetone
|
|
Halide
|
Liquid chlorine, carbon tetrachloride, trichloroethylene, chloropropylene, anhydrous hydrogen fluoride, methylene chloride, methyl chloride, titanium tetrachloride, silicon tetrachloride, phosphorus oxychloride, phosphorus trichloride, ethylene dichloride, Dichloropropylene, chloroform, trichlorosilane, aluminum chloride
|
|
Nitrogen and sulfur compounds
|
Carbon disulfide, anhydrous sulfur dioxide, hydrazine, aniline, ammonium acrylate, ethylamine
|
|
Refrigerant
|
Freon, dry ice, liquid methane, liquid ammonia
|
|
Oils
|
Petroleum derivatives, transformer oil, edible oil, lubricating oil
|
|
Heat and refrigerant
|
Dow heat carrier and other heat media, lithium bromide, methyl chloride and other refrigerants
|
|
Monomers and compounds
|
Polyvinyl chloride, polyvinyl alcohol, styrene, caprolactam, butadiene, vinyl ether, neoprene, acetonitrile
|
|
other
|
Mercury, tetraethyl lead, triethyl alkane, silane, hydrogen peroxide, plasticizer, developer gelatin, detergent, sugar solution
|
|
| |
|
|
